Professional LCD Display Digital Breath Alcohol Tester With 5 Mouthpieces





Quick Detail:

1.       Digital alcohol tester with audible alert

2.       Range: 0.00-0.19 % BAC & 0.0-1.9 g/l

3.       Quick response and resume

4.       Use mouthpiece

5.       Use 2דAAA” alkaline batteries





Specifications

Patent number: ZL 2012 30383947.7.





Features

1.        Digital alcohol tester with audible alert

2.       Range: 0.00-0.19 % BAC & 0.0-1.9 g/l

3.       Quick response and resume

4.       Auto power off

5.       Use mouthpiece

6.      Use 2דAAA” alkaline batteries





Installing battery

1.        Slide open the battery compartment lid from the back of the unit.

2.       Insert two “AAA” (UM-4) alkaline batteries with correct polarity as indicated.

3.       Replace the battery compartment lid.





How to use the alcohol tester

Warm up

1.        Press and hold the power button for 1 second, the alcohol tester LCD will turn on with one beep sound.

2.       The “warm up” symbol is displayed, and the 10 to 00 countdown is started that indicate the tester is in warm-up mode.



Note

It always has a large number of gas & impurity adsorbed on the surface of alcohol tester, when first time taking out the tester from the packaging, or after long time no using for the tester, it need more time for cleaning and warm up the sensor, you should repress the power button and retry several times if possible.



Test

1. The “Blow” symbol is displayed when warm-up is succeed, and the 10 to 00 countdown is started that indicate the tester is in testing mode.

2. Blow into the breath inhaler for 3-5 seconds with normal power after a deep inhalation..

3. Read the test result from the alcohol tester LCD.

4. The “Caution” symbol is displayed if the alcohol concentration is the level:

    0.02% BAC (or 0.2g/l) to 0.05% BAC (or 0.5g/l)

    0.05% BAC (or 0.5g/l) to 0.08% BAC (or 0.8g/l)



5. The “Danger” symbol is displayed with beep audible alert if the alcohol concentration is the level:

    Over & equal 0.05% BAC (or 0.5g/l)

    Over & equal 0.08% BAC (or 0.5g/l)

6.  If no blow into the breath inhaler at the test mode, the LCD will display “0.00 %BAC & 0.0g/l” value.

Note

To obtain more accurate result, manufacturer recommend you to check repeatedly 2 or 3 times.



Auto power off

After the result be display for about 10 seconds, the “OFF” symbol will appear for 2-3 seconds and the alcohol tester be turned off.





Backlight

When the tester is turned on, the LCD backlight will light until tester auto power off.





Replace battery

The LCD flickering indicates low power of batteries, please replace two “AAA” alkaline batteries.





Specifications

* Sensor: advanced semiconductor oxide alcohol sensor

* Range: 0.00%-0.19% BAC (0.0-1.9g/l)

* Accuracy: ±0.01% BAC (0.1g/l)

* Power input: 2×1.5V “AAA” alkaline battery

* Operating time: warm up: 10s, response: <5s

* Auto power off: 1 minute approx

* Dimension: 113×52×25mm

* Environmental temperature: 5℃-40℃

* Sensor: advanced semiconductor oxide alcohol sensor

* Range: 0.00%-0.19% BAC (0.0-1.9g/l)

* Accuracy: ±0.01% BAC (0.1g/l)

* Power input: 2×1.5V “AAA” alkaline battery

* Operating time: warm up: 10s, response: <5s

* Auto power off: 1 minute approx

* Dimension: 113×52×25mm



* Environmental temperature: 5℃-40℃





Packing details  :

Inner Packing: Gift box
QTY: 100 PCS
G.W.: 67
N.W.: 6.62KGS
MEAS: 41*37*28cm



We accept the following payment terms: T/T,L/C,O/A,D/P,D/A,WesternUnion,MoneyGram,PayPal and so on ,and we also welcome foreign buyers join us to develop new products together !
